The main difference between 230v electric power tools and 110v electric power tools is that 230v tools are compatible with domestic plug sockets, while 110v tools are mainly for on-site use. Evolution’s green DIY power tools are only available in 230v for domestic use.
The S355MCS Metal Cutting Chop Mitre Saw from Evolution is built for metalwork professionals and it's the first heavy duty 355mm cold cut Chop Saw that allows you to produce precision mitre cuts without having to reposition the workpiece.
Designed to tackle heavy cuts in oversized metal pieces the S355MCS Chop Mitre Saw features a precision adjustable mitre table, 3-position saw head and our unique, height-adjustable double front clamp rail assembly. It delivers precise and quick angle adjustment for easy set-up and a powerful clamping mechanism to ensure quality, repeatable cuts every time.
With a powerful 2,200W motor, easy ambidextrous controls, and a Bench Dog compatible base plate with a tough knurled back fence the S355MCS Mitering Chop Saw is easy to rely on for your toughest jobs. Faster than a bench band saw and much cleaner than abrasive disc or plasma cutting the S355MCS delivers, quick, accurate, angled cuts that need no rework or clean-up before final assembly.
If your fabrication work relies on your ability to make fast, repeatable, accurate, clean & cost-effective cuts through a wide variety of large diameter metal workpieces then the S355MCS Mitre Chop Saw should be your next purchase.
|Motor (240V 50Hz):||2200W|
|Motor (110V 50Hz):||1600W|
|Speed No Load:||1550 min-1|
|Max. Mitre Left & Right||+/- 46°|
|No. of Teeth:||66|
|Bore:||25.4mm / 1 In.|
|Mild Steel Plate (Max Thickness):||12mm|
|Stainless Steel Plate (Max Thickness):||5mm|
|Square Tube at 90° (Mild Steel):||120 x 120mm|
|Square Tube at 45° (Mild Steel):||100 x100mm|
|Rectangle Tube at 90° (Mild Steel):||100x 165mm|
|Rectangle Tube at 45° (Mild Steel):||100 x 110mm|
|Round Tube at 90° (Mild Steel):||Ø 120mm|
|Round Tube at 45° (Mild Steel):||Ø 110mm|
|Minimum Cut Off Piece Length:||8 mm|
|Packaging Dimensions:||450 x 760 x 584mm|
|Product Dimensions:||410 x 530 x 310mm|
|Product Weight:||35 kg|
|Packaged Weight:||40 kg|
|Sound Pressure Level LPA:||94.8 dB(A)
|Sound Power Level LWA:||107.9 dB(A)
|66 Tooth Mild Steel TCT Blade|
|Double Ended 5mm/8mm Hex Key|
|Cutting Head Assembly|
|Base Table Assembly|
|Rear Stabilising Leg|
|QR Top Clamp|
|Rail Bracket & Fixings|
|QR Front Clamps x 2|
Walk-through with DK
Features & Specifications
S355MCS Compatible Blades
